A655A: 6″ Deep Non-Drainable Blade Adjustable Louver

Additional Information

Quick Specs

Model:	A655A
Minimum Panel Size:	12″ x 12″
Maximum Panel Size:	48″ x 96″
Frame Depth:	6″ Deep
Frame Material:	.080″ Thick Extruded Aluminum 6063-T6/T52 Alloy
Blade Material:	.080″ Thick Extruded Aluminum 6063-T6/T52 Alloy
Blade Orientation:	Horizontal
Blade Type:	Non-Drainable
Blade Angle:	Adjustable
Operation:	Manual or Motorized
Bearings:	Celcon
Linkage:	Concealed in Frame
Shafts:	.50″ Diameter Aluminum “Pin-Lock” Rod
Blade Seals:	Extruded Silicone Rubber
Jamb Seals:	Polyurethane
Screen Options:	Bird Screen: ½” Flattened Aluminum.051″ Thick Variety of Bird and Insect Screen Options
Finish:	Mill
Free Area:	57% (9.06 ft² for 48″ x 48″)
Water Penetration:	800 fpm
Pressure Drop:	.15 in. w.g. at 1000 fpm and 7619 scfm

*For additional options/configurations see spec sheet or contact the factory.
